343S00105 USB Charging IC for iPad Pro 10.5 (2017) / 12.9 (2015)

Name: 343S00105 USB Charging IC for iPad Pro 10.5 (2017) / 12.9 (2015)
Brand: Apple
SKU: IP71091
Price: 6.63 USD

Apple · SKU IP71091 · Fits 1 model

$6.63

per unit

Volume pricing
Quantity	Unit price	Saving
	$6.63
	$6.30	−5%
	$5.97	−10%

Ships from Shenzhen, China. Check rates for your country
No sales tax added at checkout
Shipping & returns
Ask about fit before ordering

Shipping weight 0.01 kg

Compatible with 1 model

Match the model number printed on the device (Settings → About, or on the back) before ordering.

iPad Pro 10.5-inchA1701, A1709, A1852

Details

An iPad Pro that charges fine but won't show up on a Mac, or shows up and never charges, can share a single cause in the USB IC. The 343S00105 is a 36-pin USB charging IC listed for the iPad Pro 10.5 (2017) and the first iPad Pro 12.9 (2015).

The listing names the A1701 and A1709 for the 10.5, and the A1584 and A1652 for the 12.9. It doesn't give a board position.

Problems linked to this chip

Abnormal connection to a computer.
No charging from a working charger.
Charging that cuts in and out.
Slow charging on the original adapter.

Getting at the board

Rule out the cable, the charger and the charge port first. iPad Pro screens are laminated and fragile, so use gentle heat and plenty of picks to lift them. Disconnect the battery before you touch the logic board.

Find the chip with the board view, shield nearby parts and lift it with hot air. Fit the new one on fresh flux, then test charging and a computer connection before closing the iPad.

Specifications

Condition	New
Part number	343S00105
Part type	USB charging IC
Pin count	36
Compatible devices	iPad Pro 10.5 (2017), iPad Pro 12.9 (1st gen, 2015)
Model numbers	A1701, A1709, A1584, A1652
