LUOWEI D3 FA Motherboard Hold Fixture

Name: LUOWEI D3 FA Motherboard Hold Fixture
Brand: LUOWEI
SKU: LW10097
Price: 16.8 USD

LUOWEI · SKU LW10097

$16.80

per unit

Volume pricing
Quantity	Unit price	Saving
	$16.80
	$15.96	−5%
	$15.12	−10%

Ships from Shenzhen, China. Check rates for your country
No sales tax added at checkout
30-day returns on unused parts. Details
Ask about fit before ordering

Shipping weight 0.4 kg

Details

The LUOWEI D3 FA is a flat metal fixture that holds a phone motherboard in place at several points while you work on it.

The listing describes multi-point clamping, an adjustable layout for different board shapes, an anti-slip structure and a heat-resistant base. The only figures given are a packed size of 14 x 9 x 3 cm and 350 g gross weight.

When a flat fixture is enough

A failed IC you are removing with hot air.
Damaged capacitors that need replacing on the top side.
A short you are tracing on a board connected to a supply.
Liquid residue you are cleaning with alcohol and a brush.

Practical notes

Clamp on bare edges or screw holes, and spread the grip evenly so the board doesn't bow under heat. Let the board cool before you release it.

Choose the D3 FA if you work flat under a microscope and want a simple, firm hold. If you often need to tilt the board, the AP06 FO and AP05 DAO add dual-axis adjustment, which costs a little more bench height. Wipe flux off the clamp points after each job.
