DJI Mini 5 Pro ESC Board

$49.35

per unit

Volume pricing
Quantity	Unit price	Saving
	$49.35
	$46.88	−5%
	$44.42	−10%

Ships from Shenzhen, China. Check rates for your country
No sales tax added at checkout
Shipping & returns
Ask about fit before ordering

Shipping weight 0.05 kg

Compatible with 1 model

Match the model number printed on the device (Settings → About, or on the back) before ordering.

DJI Mini 5 Pro

Details

On the bench, a Mini 5 Pro with uneven motor rotation or ESC errors is checked in a set order, because the ESC board is the most expensive of the likely causes. The motors, the arm wiring and the ESC flat cable all come first.

This ESC board is listed for the DJI Mini 5 Pro and regulates speed and power for all four motors. The listing doesn't say who makes it, so it's an aftermarket part.

Mini 5 Pro bench order for motor faults

Spin each motor by hand; grinding or rough spots mean the motor itself.
Check the arm wiring for breaks at the fold.
Inspect the ESC flat cable for creases or scorching.
If several motors misbehave, or a healthy motor won't start, replace the ESC board.

After the swap

Work with the battery out and photograph each connection first. Once the board is in, run the motors without propellers and listen for even sound, then hover low before a normal flight.

Diagnosed in this order, the repair fixes the actual fault and gets the Mini 5 Pro flying evenly again. Check any DJI warranty or Care Refresh coverage before opening a drone this new.
